Top Case for Vespa LX single Red Dragon 894 - 32 liters
- Manufacturer: Piaggio (Original OE)
- Item no: 67394900R7
- Manufacturer no.: 67394900R7
- EAN: 4060861008931
Item data
| Product type: | Top Case |
| Capacity: | 32 L |
| Color code: | 894 red - dragon |
| Tuning & Styling Part: | Yes |
| Vintage part: | No |
| Mounting method: | Screw-on |
| Surface finish: | Lacquered |
| Universal compatibility: | No |
| Fixing type: | Screw-on |
| OE/OEM reference number(s): | Piaggio 67394900R7 |
| GTIN: | 4060861008931 |
| Scope of delivery: | 2 keys |
| Color: | Red |
| Features: | Anti-theft lock, integrated reflector, Vespa lettering in chrome |
| Manufacturer number: | 67394900R7 |
| Country and region of manufacture: | Italy |
| Brand compatibility: | Vespa |
| Width: | 420 mm |
| Installation position: | Rear |
| Height: | 310 mm |
| Type of motorcycle: | Scooter |
| Length: | 350 mm |
| Description of the package content: | Topcase |
| Manufacturer warranty: | 2 years |
| Material: | Plastic |
Cylinder kit 50cc including cylinder head + valves for China scooters, Baotian, Rex RS450
Cylinder kit 50cc Minarelli AC air-cooled horizontal engines, CPI, Rexy, Keeway
Cylinder kit 50cc AC air-cooled 12mm bolt angled flange for horizontal CPI engines, CPI, Keeway
Cylinder Kit 70cc LC watercooled incl. head for Piaggio engines, NRG, ZIP, NTT, Gilera Runner
Top Case Vespa Primavera 50 125 Relax Green 350/A - 32 liters - Original Piaggio
Original Piaggio Vespa LX Top Case 32 liters in Dragon Red 894
DESCRIPTION:
Original Piaggio top case for Vespa PX as well as S50, S125, S150. also suitable for Vespa LX, LX Touring, GTS, GTS Super, Primavera, Sprint and ET2, ET4.
ADVANTAGES:
- Original spare part
- Painted in vehicle color
- Capacity 32 liters
- Chromed Vespa lettering
- Reflector
- Lockable
TECHNICAL DATA:
- Version: Top Case
- Color: red - Dragon 894
- Dimensions LxWxH: 350 mm x 420 mm x 310 mm
- Capacity: 32 liters
NOTES:
VESPA PX
The Vespa PX models require the rigid top case carrier (item no. 7673139) for mounting.
VESPA S / VESPA LX
Mounting on Vespa LX and Vespa S is done using the rigid top case carrier (item no. 7676370), which must be ordered separately.
To mount this single Top Case on the standard folding luggage carrier of the Vespa LX Touring a special mounting kit must be ordered or the original folding luggage carrier must be exchanged for the rigid chrome carrier.
VESPA ET2 / ET4
For Vespa ET2 and ET4 , as well as the Vespa GT the mounting is possible without problems on the standard aluminum luggage carrier.
VESPA GTS
By means of a special luggage carrier (article no.: 657081) the mounting of the case is also possible on the Vespa GTS. This alternative offers itself for everyone, who wants e.g. a smaller suitcase for his Vespa. Also, the original "large" top case for the Vespa GT/GTS is no longer offered in all colors, but the "small" top case described here is.
FIND COLOR CODE:
Attention: there is no Vespa that is simply red, but each Vespa has its own color code. You can find it as follows: Open the seat, take out the helmet compartment. On the frame is a white or silver sticker. There is the chassis number and very important the color number. If you remember this, you will know if the accessories match in color and avoid unnecessary sending back and forth.
MATCHING ACCESSORIES:
A perfect, matching inner bag of the original Vespa Vintage series made of textile mix is also available (item no.: 7673132).
SCOPE OF DELIVERY:
✔ Original Piaggio Top Case for Vespa PX as well as S50, S125, S150, red Dragon 894.
