Bowdenzug Set schwarz für Zündapp ZD 30 Typ 446-200 (FG-Nr. 9235093 - 9744036)
- Manufacturer: Citomerx
- Item no: 168432
- Manufacturer no.: 168432
- EAN: 4060861187841
Item data
| Product type: | Bowden cable set |
| Throttle cable Special feature: | with deflection (motor side) |
| Brake cable front diameter cover / cable: | 5.0 / 1.5 mm |
| Decompression train Special feature: | Zum selbst kürzen! |
| Restriction vehicle: | from FG no. 9235093 - 9744036 |
| Rope material: | Steel |
| Front brake cable Length of sheath / cable: | 860 / 980 mm |
| Tuning & Styling Part: | No |
| Cover material: | PVC |
| Vintage part: | Yes |
| Shifter cable diameter cover: | 4,8 / 1,50 mm |
| Clutch cable diameter cover / cable: | 5.0 / 1.5 mm |
| Throttle cable diameter sheath / cable: | 5.0 / 1.3 mm |
| Decompression pull diameter envelope / rope: | 5,0 / 1,5 mm |
| Universal compatibility: | No |
| Model compatibility: | Zündapp |
| Shift cable length cover / cable: | 900 / 1040 mm |
| Clutch cable length cover / cable: | 930 / 1000 mm |
| Decompression pull length envelope / rope: | 1000 / 2000 mm |
| OE/OEM reference number(s): | 446-17,611 (decompression train), 446-17.613 (clutch cable), 446-17.616 (shift cable), 446-17,645 (brake cable), 447-17.613 (throttle cable) |
| GTIN: | 4060861187841 |
| Throttle cable length sheath / cable: | 770 / 910 mm |
| Note: | Please compare recordings and length! |
| Color: | Black |
| Scope of delivery: | 1x Bowden cable set |
| Manufacturer number: | 168432 |
| Country and region of manufacture: | China |
| Brand compatibility: | Zündapp |
| Installation position: | Links, Right |
| Type of motorcycle: | Road motorcycle |
| Offer package: | Yes |
| Description of the package content: | Throttle / brake / clutch / gearshift / deco cable |
| Manufacturer warranty: | 2 years |
Cylinder kit 50cc including cylinder head + valves for China scooters, Baotian, Rex RS450
Cylinder kit 50cc Minarelli AC air-cooled horizontal engines, CPI, Rexy, Keeway
Cylinder kit 50cc AC air-cooled 12mm bolt angled flange for horizontal CPI engines, CPI, Keeway
Cylinder Kit 70cc LC watercooled incl. head for Piaggio engines, NRG, ZIP, NTT, Gilera Runner
Bowden cable set black for Zündapp ZD 25 type 446-420 (up to FG no. 9199883)
Zündapp Original-/Vergleichsnummer:
447-17.613 (Gaszug)
446-17.645 (Bremszug)
446-17.613 (Kupplungszug)
446-17.616 (Schaltzug)
446-17.611 (Dekozug)
TECHNISCHE DATEN:
- Farbe: Schwarz
- Material Hülle: PVC
- Material Seil: Stahl
- Hinweis: Bitte Aufnahmen und Länge vergleichen!
GASZUG
- Länge Hülle: 770 mm
- Länge Seil: 910 mm
- Durchmesser Hülle: 4,8 mm
- Durchmesser Seil: 1,3 mm
- Aufnahme 1: Tonnennippel Ø5,2 x 7 mm
- Aufnahme 2: Birnennippel Ø3 x 3,5 mm
- Bowdenzugspanner: M6-Gewinde
- Besonderheit: mit Umlenkung
BREMSZUG
- Länge Hülle: 860 mm
- Länge Seil: 985 mm
- Durchmesser Hülle: 4,8 mm
- Durchmesser Seil: 1,5 mm
- Aufnahme 1: Birnennippel Ø5,8 x 9 mm
- Aufnahme 2: Birnennippel Ø5,8 x 9 mm
- Bowdenzugspanner: M6-Gewinde
KUPPLUNGSZUG
- Länge Hülle: 930 mm
- Länge Seil: 1000 mm
- Durchmesser Hülle: 5,3 mm
- Durchmesser Seil: 1,5 mm
- Aufnahme 1: Birnennippel Ø6 x 8 mm
- Aufnahme 2: Tonnennippel Ø6 x 7,5 mm
- Bowdenzugspanner: M6-Gewinde
SCHALTZUG
- Länge Hülle: 900 mm
- Länge Seil: 1100 mm
- Durchmesser Hülle: 5,9 mm
- Durchmesser Seil: 1,5 mm
- Aufnahme 1: Tonnennippel Ø6 x 6 mm
- Aufnahme 2: Tonnennippel Ø7,8 x 14,5 mm
- Bowdenzugspanner: M6-Gewinde
DEKOMPRESSIONSZUG
- Länge Hülle: 1000 mm
- Länge Seil: 2000 mm
- Durchmesser Hülle: 5 mm
- Durchmesser Seil: 1,5 mm
- Aufnahme 1: Birnennippel Ø3,2 x 5,2 mm
- Aufnahme 2: Tonnennippel Ø5 x 7 mm
LIEFERUMFANG:
1x Bowdenzug Satz
Zündapp ZD 30 Typ 446-200 (ab FG-Nr. 9235093 - 9744036) BING 15mm / 120mm Trommel
