DellOrto carburetor 04131 PHBH 28 NS for Cagiva Super City Kat (Switzerland) BJ 1992 125 ccm
- Manufacturer: Dellorto
- Item no: 999904131
- Manufacturer no.: 04131
- EAN: 4251048835574
Item data
| Product type: | Carburetor |
| Country of origin: | Italien |
| Number of mixing chambers: | 1 |
| Connection Type (Motor Side): | Steck |
| Side Adjustment Screw: | S |
| Series: | PHBH |
| Connection Type: Air Filter Side: | Gewinde |
| Main jet (type / thread / size): | 6413-130 / M6 / 130 |
| Dellorto Carburetor Number: | 04131 |
| Idle jet (type / thread / size): | 1486-38 / M5 / 38 |
| Air filter side connection: | M42 x 1,25 |
| Tuning & Styling Part: | No |
| Vintage part: | No |
| Universal compatibility: | No |
| ATTENTION: | Vergaser auch für andere Modelle passend! Maße vergleichen! |
| Connection motor side: | 36 mm |
| GTIN: | 4251048835574 |
| Lubrication: | Getrennt |
| Note: | Vergaser grundeingestellt. Abstimmung muss nach Einbau erfolgen! |
| Scope of delivery: | Carburetor |
| Comparison number: | Dellorto 04131, Dellorto 4131 |
| Throttle cable: | Winkel |
| Color: | Grey |
| Culvert: | 28 mm |
| Engine type: | 2-stroke |
| Secondary nozzle: | 11600-70 / M4 / 70 |
| Scope of delivery: | 1x carburetor |
| Manufacturer number: | 04131 |
| Installation position: | Engine compartment |
| Type of motorcycle: | Moped & Mokick |
| Units quantity: | 1 |
| Manufacturer warranty: | 2 years |
| Material: | Metal |
| Type: | PHBH 28 NS |
Prices plus VAT plus shipping costs
In stock! Delivery time 1-3 working days
Rear light complete model "classic/vintage" for mokick moped moped
Cylinder kit 50cc including cylinder head + valves for China scooters, Baotian, Rex RS450
Cylinder kit 50cc Minarelli AC air-cooled horizontal engines, CPI, Rexy, Keeway
Cylinder kit 50cc AC air-cooled 12mm bolt angled flange for horizontal CPI engines, CPI, Keeway
Cylinder Kit 70cc LC watercooled incl. head for Piaggio engines, NRG, ZIP, NTT, Gilera Runner
With an original Dell'Orto carburetor, you get quality at the highest level.
In principle, the various carburetors can be freely interchanged. The size of the passage essentially determines the quantity of the fuel-air mixture and must be selected according to the corresponding engine capacity. The engine and air-side connections can usually be adapted using adapters.
The carburetors of the PHB series are among the most common models in the 50-125cc class. PHB carburetors are used on the majority of mopeds, mopeds and scooters. They are the standard for Minarelli engines.
Technical data:
Type PHBH Var. N with 28 mm passage, separate lubrication:
- Adjusting screws left
- Flange connection rubber Ø36mm
- Angled throttle cable
- Folding choke
- Air filter connection
equipped with:
- Air filter connection 10001-82
- Throttle slide 13112-40
- Carburetor needle X 9477-58
- Main atomizer DV1 13113-262
- Main jet 6413-130
- Secondary jet 11600-70
- Idle jet 1486-38
- Starter jet 7746-65
- Needle valve 9436-200
- Float 9010-01, 9,5gr
Suitable for the following models:
This carburetor is used exactly in this configuration (jets, atomizer, connections, etc.) in the following models: Cagiva Super City Kat (Switzerland), BJ 1992, 125 ccm, 1 cyl. - 2-stroke
Of course, the carburetor can also be used in other models. The air intake, the engine connection and the connection for the throttle cable and the choke may have to be adapted, and carburetors for 2 and 4-stroke engines should not be mixed. It is also important to check whether the carburetor is prepared for mixed or separate lubrication and whether any vacuum connections are required to control a fuel tap or an oil pump.
