Cylinder ORIGINAL PIAGGIO 125 cc AC 2 stroke SKR Skipper Aprilia SR TPH
- Manufacturer: Piaggio (Original OE)
- Item no: 829984
- Manufacturer no.: 829984
- EAN: 4060861008818
Item data
| Product type: | Cylinder set |
| Country of origin: | Italien |
| Displacement: | 125ccm |
| Tuning & Styling Part: | No |
| Vintage part: | No |
| OE/OEM reference number(s): | 829984, 430208, 487545 |
| GTIN: | 4060861008818 |
| Scope of delivery: | Piston, Piston rings, Retaining rings, Cylinder |
| Comparison number: | Piaggio 829984 |
| Piston pin diameter: | 16 mm |
| Engine type: | 2-stroke |
| Drill hole: | 55 mm |
| Scope of delivery: | 1x cylinder set |
| Manufacturer number: | 829984 |
| Country and region of manufacture: | Italy |
| Type of motorcycle: | Scooter |
| Units quantity: | 1 |
| Material: | Aluminum |
Prices plus VAT plus shipping costs
In stock! Delivery time 1-3 working days
Adjustment Screw 146197 - Original Oil Pump Cable Adjuster for Piaggio Aprilia Derbi Gilera
NGK Spark Plug BR9ES 5722 for Scooter, Motorcycle, Moped – Part Number 105011
Cylinder kit 50cc including cylinder head + valves for China scooters, Baotian, Rex RS450
Cylinder kit 50cc Minarelli AC air-cooled horizontal engines, CPI, Rexy, Keeway
Cylinder kit 50cc AC air-cooled 12mm bolt angled flange for horizontal CPI engines, CPI, Keeway
Cylinder Kit 70cc LC watercooled incl. head for Piaggio engines, NRG, ZIP, NTT, Gilera Runner
Original Piaggio Cylinder 50cc for NRG Power MC3, Zip 2, Gilera Runner Purejet – OEM 833598
Cylinder Kit Complete Original Piaggio Vespa APE Car P2, P601V 220 Part Number 2431175
Cylinder set 50cc 40mm (stud distance 44mm) flanged manifold (NEW EDITION) for Kreidler
Cylinder Piaggio 180 cc LC Gilera Runner Hexagon Italjet Dragster 125 150 180 LX
Clear glass headlight original Piaggio 35/35W HS1 for Piaggio TPH X XR 50 80 125
Piaggio Zylinder 50 ccm AC NRG TPH X ZIP FR LX V Free Storm Ball ET 2
Cylinder ORIGINAL PIAGGIO 125 cc AC 2 stroke SKR Skipper Aprilia SR TPH
DESCRIPTION:
You still have such a great 125 ccm Piaggio / Aprilia scooter with 125 ccm two-stroke engine and air cooling? Take good care of it, because such a lively and fast scooter is no longer available for 15 years due to the constant new emission standards.
With the rattling two-stroke you have no opponents in the city and on the highway you can really glow with it. If then nevertheless times the cylinder makes flabby, we have for you the suitable replacement, as Piaggio original spare part.
TECHNICAL DATA:
Cylinder:
- Displacement: 123 cm³
- Bore: 55 mm
- Engine type: 2-stroke
- Cooling type: air cooled
- Material: aluminum
- Piston skirt material: ceramic
- Cylinder head included
- Cylinder gasket set included
- Number of overflow ports (incl. boost ports): 6
- Number of boost ports: 2
- Exhaust shape: 1-piece (oval)
- Exhaust mounting: Flange
- Flange type: 2-bolts
- Distance exhaust studs: 60 mm
- Thread exhaust studs: M8
Crankshafts:
- Stroke: 52 mm
Pistons:
- Number of piston rings: 2
- Type of manufacture piston: cast
Piston rings:
- Piston ring type: rectangular ring
- Thickness piston rings : 1,2mm
Piston clips :
- Piston clip type: C type
- Wire thickness piston clip : 1.0mm
- OEM numbers (for reference only): Piaggio 829984
SCOPE OF DELIVERY:
✔ Cylinder ORIGINAL PIAGGIO 125 cc AC 2 stroke SKR Skipper Aprilia SR TPH
Piaggio & C. SpA
Viale Rinaldo Piaggio 25
56025 Pontedera
Telephone number: +39 0587.272111
Web page http://www.de.piaggio.com/
Email: info@piaggio.com
| Product type | Cylinder set |
|---|---|
| Country of origin | Italien |
| Displacement | 125ccm |
| Tuning & Styling Part | No |
| Vintage part | No |
| OE/OEM reference number(s) | 829984, 430208, 487545 |
| GTIN | 4060861008818 |
| Scope of delivery | Piston, Piston rings, Retaining rings, Cylinder |
| Comparison number | Piaggio 829984 |
| Piston pin diameter | 16 mm |
|---|---|
| Engine type | 2-stroke |
| Drill hole | 55 mm |
| Scope of delivery | 1x cylinder set |
| Manufacturer number | 829984 |
| Country and region of manufacture | Italy |
| Type of motorcycle | Scooter |
| Units quantity | 1 |
| Material | Aluminum |
Piaggio original spare parts - 100% quality & precision fit
Piaggio is one of the most traditional manufacturers of scooters and mopeds in the world. With genuine spare parts from Piaggio, you are opting for maximum reliability, tested safety and a perfect fit. Whether for classic models or modern scooters - Piaggio original parts are specially developed for your vehicle and guarantee a long service life and optimum performance.
Why Piaggio original spare parts?
- ✅ 100% suitable - precisely matched to Piaggio models.
- ✅ Tested manufacturer quality - identical to original equipment.
- ✅ Durable & robust - developed for daily use.
- ✅ Safety - maximum reliability and tested standards.
- ✅ Value retention - original parts maintain vehicle value and function.
Popular Piaggio spare parts
Engine & drive
Cylinders, pistons, crankshafts, variator systems and belts - all in original quality for flawless performance and high mileage.
Brakes & clutch
Brake pads, brake discs, clutches and bells - perfectly matched for safety and control.
Carburetor & electrics
Original carburetors, CDI, ignitions and alternators ensure the reliable functioning of all engine and electronic components.
Seals & chassis
Seals, shock absorbers and suspensions guarantee optimum chassis and engine performance.
Bodywork & accessories
Original body parts, mirrors and accessories ensure a flawless appearance and a perfect fit.
Technical advantages
Piaggio original parts are manufactured under the same conditions as the original equipment and are designed for maximum precision and resilience. Unlike replica or universal parts, they guarantee perfect integration and maximum service life. This keeps your Piaggio scooter in top condition at all times.
Buying advice in a nutshell
- ✅ Engine: Original cylinders & pistons for maximum durability.
- ✅ Drive: Variomatic transmission & drive belt for optimum power transmission.
- brakes: pads & discs for maximum safety.
- electrics: CDI, ignitions & alternators especially for Piaggio.
- fairing: Original parts for a perfect look & fit.
Conclusion
Piaggio original spare parts stand for absolute accuracy of fit, tested quality and durability. They are the best choice for riders who value reliability, safety and value retention. Whether you need to repair, maintain or restore your scooter, genuine Piaggio parts will keep your vehicle in top condition.
