Pinion 16 teeth pitch 415 type 0820 for Zundapp CS GTS KS RS 50 type 448 515 517 529 561
- Manufacturer: Citomerx
- Item no: 277-05.157
- Manufacturer no.: 714196
- EAN: 4251048859334
Item data
| Product type: | Chain sprocket |
| Division: | 415 (1/2 x 3/16 x 7.75) |
| Shaft mounting form: | round toothed |
| Vintage part: | Yes |
| Shaft mounting Dimensions: | 15.3 / 17.0 mm |
| Universal compatibility: | No |
| Chainring thickness: | 3/16" (4.60 mm) |
| Compatible year: | not specified |
| Model compatibility: | not specified |
| Pinion tuning note 1: | More teeth -> more top speed / less acceleration |
| OE/OEM reference number(s): | 277-05.157 |
| Pinion tuning hint 2: | Fewer teeth -> better acceleration / less top speed |
| ATTENTION!: | Change in the number of teeth -> Cancellation of operating license! |
| GTIN: | 4251048859334 |
| Note: | Note the original translation! |
| Compatible chain link length: | 1/2" (12.70 mm) |
| Color: | Grey |
| Total width: | 13.00 mm |
| Scope of delivery: | 1x chain sprocket |
| Manufacturer number: | 714196 |
| Country and region of manufacture: | China |
| Brand compatibility: | Zündapp |
| Installation position: | Front |
| Type of motorcycle: | Moped & Mokick |
| Manufacturer warranty: | 2 years |
| Diameter: | 65.00 mm |
| Material: | Steel |
| Type: | 0820 |
Prices plus VAT plus shipping costs
In stock! Delivery time 1-3 working days
